Garrett GBC17-250 Turbocharger 0.50 A/R IWG 896052-5003S

€719.55
Content: 1 Stück

Prices incl. VAT plus shipping costs

Delivery time approx. 5 working days

  • 896052-5003S
Horsepower: 150 - 250 HP Displacement: 0.6 - 1.5 L T25 Inlet - 5-Bolt Outlet - Single... more
Garrett GBC17-250 Turbocharger 0.50 A/R IWG 896052-5003S

Horsepower: 150 - 250 HP
Displacement: 0.6 - 1.5 L
T25 Inlet - 5-Bolt Outlet - Single Scroll - Internal Wastegate - A/R 0.50

Honeywell Garrett GBC-Series - The new Boost-Club-Line turbocharger!
These very small turbocharger achieve extremely high performance with minimum space requirements.

  • Latest CFD-optimized, forged milled compressor wheel
  • Rotation: Standard (Clockwise)
  • Latest generation of journal bearing rotor group
  • 360-degree thrust bearing
  • Ductile iron (SiMo+) turbine housing material
  • Inconel turbine wheel material
  • Oil cooled center housing
  • Internal Wastegate incl. 0.5 bar Actuator
  • Delivery: Turbocharger

Compressor side:

It uses the latest generation of CFD-designed compressor wheels.

Center Housing:

The center section is attached to the exhaust housing over an V-band and can thus easily rotate 360° into any position.

Turbine side:

The completely redesigned turbine wheel, made of the high-performance material Inconel, enables exhaust gas temperatures up to 980° C.

Compressor side:
Inducer ø
36.00mm
Exducer ø
49.00mm
Trim
55
A/R
0.52
Turbine side:
Inducer ø
44.00mm
Exducer ø
40.00mm
Trim
80
A/R
0.50

We are the only Garrett Performance Distributor for Germany and will support you with any questions about these turbocharger or would help to design your project.
